Measurement Features
- Geometry tools for points, lines, circles, arcs, ellipses, slots, curves, planes, spheres, cylinders and cones.
- Constructed features including centers, parallel lines, tangents and inscribed or circumscribed circles.
- Autofocus, edge finding, lighting control, CAD-assisted measurement, barcode reading and map navigation on compatible configurations.
- Supported sensor configurations include touch probes, 3D line lasers, chromatic confocal sensors and other optical sensors.
- Export measurement reports to Excel, PDF, Word and TXT with configurable presentation.
- Temperature and proportional compensation modes support configured measurement corrections.
Model Specifications
Compare the configuration and measurement range for your parts.
| Parameter | iVISION |
|---|---|
| Reporting formats | Excel, PDF, Word, TXT |
| Programming support | CAD import, automatic feature finding, batch programs |
| Compensation modes | Temperature mode and proportional mode |
| Basic operator training | Typically 1–2 hours for basic tasks; advanced programming requires additional training |
| Configuration dependency | Hardware, sensor and integration options determine available functions |
Configuration & Specification Notes
Confirm supported CAD versions, operating system, language, hardware interfaces, license terms and integration scope in the quotation. A supported sensor type is not necessarily included in the base machine.
Software capabilities do not establish the accuracy of an installed system. Use the machine specification and application validation.
Evaluate Your Application
Send your part drawing, critical tolerances, dimensions, material and inspection volume. Navinertia Tech will help select a model, optics and sensors for a sample evaluation.
Standard Integration and Software Scope
No additional integration charge applies only to the standard functions and interfaces expressly listed in the quotation. Optional modules, custom development, third-party licenses and on-site work may incur separate charges. License and update entitlements are confirmed for the quoted configuration.Service scope and measurement conditions.
